| Model | LFP-51.2V300Ah | LFP-51.2V314Ah |
|---|---|---|
| Battery Type | LiFePO4/LFP | |
| Configuration | 16S1P | |
| Rated Energy | 15.36kWh | 16.0kWh |
| Nominal Voltage | 51.2V | 51.2V |
| Working Voltage | 40V to 58.4V | 40V to 58.4V |
| Capacity | 300Ah | 314Ah |
| Recommended Charge Current | ≤40A | ≤40A |
| Max. Charge | 200A | 200A |
| Max. Discharge | 200A | 200A |
| Cycle Life (@25 °C) | > 8,000 Cycles @ 80% DoD | |
| Extensibility | Up to 15 batteries in parallel | |
| Working Temperature (Charge) | 0 to +65 °C | |
| Working Temperature (Discharge) | -20°C to +65 °C | |
| Storage Temperature | -20°C to +30 °C | |
| Max. Altitude | ≤3000m | |
| Humidity | 5% to 95% | |
| Communication | CAN/ RS485/Bluetooth/WIFI | |
| Dimensions(L*W*H) | 700*500*297.5mm | |
| Weight | 121.5kg | |
| Mounting | Wall, Movable | |
| Ingress Protection | IP20 | |
Packages
Certificate
Our products certified by CE, UL, Saber, ROHS, ISO9001 ,and ISO1400…
Overseas Service Center
Local service areas include: Netherlands, Germany, Luxembourg, Portugal, Spain, Dubai, Saudi Arabia, Malaysia.
Project Case
How to place an order to configure a product
Purchase Order
Recommends products based on needs, can help develop programs
Optional Products
Identification of products and development of production plans
Procurement and Production
Procurement of raw materials and aging tests to ensure qualified product quality
Shipment
Packing and shipping and after-sales service
