● Customized plug (EU/Us/CN)
● UPS response time is less than 20ms
● Fast charging: can be fully charged in 1 hour
● Maximum output voltage 230V, can charge the car
PERFORMANCE SPECIFICATIONS | |
Model | FP-5000 |
PV DC Input Side | |
Max Power | 4500W |
Max Voltage | 145V |
MPPT Voltage Range | 60-115V |
Max Current | 80A |
No. Of MPPT | 1/2 |
Grid/Charging Pile Charging Parameters | |
Max Charging Current | 60A |
Rated Grid Voltag Grid Voltage Range | 110V/220V/230V AC90-264VAC |
Rated Frequency | 50Hz(45-54Hz)/60Hz(55-65Hz) |
Emergency Power Output | |
Rated Power | 5000W |
Rated Voltage | 230V AC(110V/220V) |
Rated Frequency | 50/60HZ |
Response Time | 20ms |
Battery Parameters | |
Rated Voltage | 51.2V |
Max. Charge and Discharge Power | 4500W&5000W |
Capacity | 100Ah |
Voltage Range | 40-58.4V |
Max. Charge & Discharge Current | 100A |
Other Parameters | |
Capacity | 5KWh |
Weight | 70Kg |
Size(L*W*H) | 485*332*630mm |
Cooling Methods | Air Cooled |
Operating Temperature(°C) | 0°C~55°C |
Relative Humidity | 5-95%,non-condensing |
Protection Level | IP54 |
