● Industry leading smart monitoring system with the LCD touch screen
● Self-developed inverter protocol conversion module
● Compatible with 15+ brands inverter
● Long-lasting 6500 +cycles with 10 years warranty
● Accept OEM design of hardware and software
● IEC, UL, CE, ROHS, UN383, MSDS certified
● Bluetooth/ WIFI function(optional ) check the statusand performance from your
phone
| PERFORMANCE SPECIFICATIONS | |||
| Model | FW-801 | ||
| Nominal Voltage | 51.2V(16series) | ||
| Nominal Capacity | 100AH | 150AH | 200AH |
| Rated Energy(KWH) | 5.12kwh | 7.68kwh | 10.24kwh |
| Internal Resistance | ≤30mΩ | ||
| Cycle Life |
≥6500 cycles@ 80% DOD,25℃,0.5C ≥4000 cycles@ 80% DOD,40℃,0.5C |
||
| Design Life | ≥10 years | ||
| Charge Cut-off Voltage | 56V±0.5V | ||
| Max.Continuous Work Current | 100A/150A(Can Choose) | ||
| Discharge Cut-off Voltage | 45V±0.2V | ||
| Charge Temperature | 0℃~60℃(Under 0℃ extra heating mechanism) | ||
| Discharge Temperature | -20℃~60℃(Under 0℃ work with reduced capacity) | ||
| Storage Temperature |
-40℃~55℃@60%±25% relatuive humidity |
||
| Dimensions(mm) | 680*485*180 | ||
| Weight | 62kg | 79kg | 98kg |
| Protocol | RS485/RS232/CAN | ||
